I really enjoy industrial design and heavy keyboards. While the group buy for the HMKB was running I didn’t pull the trigger because I had other outstanding GBs. Luckily there were some extras left when it finally finished in 2023.

Facts

Model no.HMKB 40
ManufacturerHeavy Metal Keyboards
Manufacture Date2023
CaseBent steel top and bottom case
PlateAluminium
SwitchesGAZEW Boba U4
KeycapsMT3 3277
Dimensions355 × 110 × 35 mm
Weight1000 gram
PCB/SoftwareEon40 + QMK

Highlights

Layouts

Qwertz layer

Esc CpsLck
Q
W
E
R
T
Z
U
I
O
P
BS
Tab Fn
A
S
D
F
G
H
J
K
L
+
#
Shift
Y
X
C
V
B
N
M
,
.
-
SftEnt
Ctrl
Alt Shift
Gui
Alt
AlGr
Gui
Fn
Ctrl

The default layer is mostly german-ISO. I use some combined keys with different keys for tap and hold. The Return key is Shift on hold, the Tab key activates the function layer on hold. Esc is toggling Caps Lock on double-tap.

Function layer

^←
^→
ü
Del
^1
PgUp
ö
ä
PgDn
Home
End
ß
Print
Scroll
Pause
▶️
🔉
🔊

The function layer contains the navigation and arrow keys on the right hand. The arrow keys are directly on the homing key so they can be used by only moving my left pinky one key left.

In addition to the german “umlaute” and the delete key on backspace the shortcut ctrl-1 I use in my IDE is in a very convenient place.

Lower (blue) layer

^
F7
F8
F9
F12
7
8
9
=
F4
F5
F6
F11
4
5
6
Ins
F1
F2
F3
F10
1
2
3
0
,
.

The lower layer contains the number keys in the orientation used on number pads on full-size keyboards. The 4 is on the homing-key instead of the 5 so I don’t have to move the hand one key over to enter numbers.

The function keys follow the same pattern on the left hand. In addition i added the = key on this layer.

Raise (orange) layer

°
!
"
§
$
%
&
/
(
)
?
{
}
´
\
|
[
]
<
>

The raise layer contains the brackets/parathesis keys on the right hand in the order of frequency I use them and the ?, | and \ keys. The top row follows the symbols as on full-sized keyboards.
